1000kg Heavy Duty Electric Pallet Jack Lithium Power – EX-540/685

  • The lifter is rated to support up to 1000kg, making it suitable for lifting and transporting heavy loads in industrial and warehouse environments.
  • One-cylinder system guarantees smooth and stable lifting, providing a reliable lifting mechanism without the risk of sudden drops from the second piston.
  • Designed with the newest handle design that meets ergonomic requirements, offering comfortable and easy control for operators during use.
  • Features a quick lift function that doubles the lifting speed for loads weighing 1000 kg or less, increasing efficiency during lifting and reducing downtime.
  • Conforms to CE safety standards, ensuring that the lift meets all required safety regulations for operation within the European market.
  • Lifting is powered both manually and electrically, allowing operators flexibility depending on power availability and operational needs.
  • Lowering is manual, ensuring precise control when lowering heavy loads in a safe and controlled manner.
  • Conforms to EN1757-4 and EN1175 safety standards, providing assurance that the lift meets rigorous European safety requirements for industrial equipment.
  • Equipped with a built-out battery and charger, the lift achieves a low centre of gravity, enhancing stability and improving manoeuvrability even when carrying heavy loads.
Model EX-540 EX-685
Capacity 1000 kg 1000 kg
Min. Fork Height 85 mm 85 mm
Max. Fork Height 800 mm 800 mm
Width of Overall Fork 540 mm 685 mm
Length of Fork 1170 mm 1170 mm
Size of Fork 160 x 50 mm 160 x 50 mm
Fork Roller 75 x 50 mm 75 x 50 mm
Big Wheel 180 x 50 mm 180 x 50 mm
Battery (5hrs) 12V / 60 Ah 12V / 60 Ah
Weight 169 kg 169 kg
Warranty 1 year 1 year
